Reference 6.5 inch 2-way Component System with Separate
X-Over 100 WRMS

DLS knows that the small details eventually make a
difference, therefore we always keep that in mind when we
design and develop new products.
One perfect example of this is the DLS original new
antivibration PENTA basket.
When the magnet motor of a speaker can work without being
affected by external vibrations, the sound becomes tighter
and clearer.
In the DLS PENTA basket, the strong steel basket is
reinforced by precision pressed structures running on the
sides of each pillar, creating a very rigid assembly plane
for the magnet.
To further cancel out resonant vibrations the asymmetrical
shape with five rather than the usual four pillars,
also play an important role to avoid mechanical structure
standing waves.

The RC6.2Q boast DLS original design, anti-vibration PENTA
basket and DLS imprinted logos.
The large magnet, rigid aluminum cone woofer has a special
rubber dust cap that improves mid/high frequency
reproduction and the 28mm silk dome together with a
high-grade component crossover give you all the bass power,
clarity and warmth that define DLS speakers.

Specifications

Woofer size 16,5 cm (6,5 )
Tweeter RC28, 28 mm (1,25 ) silk dome tweeter with copper
rings
Power handling capacity 100 W RMS / 150 W max / 300 W peak
power
Impedance 4 ohm
Frequency range 50 - 25 000 Hz
Sensitivity 90 dB (1W/1m)
Crossover Filter box with 6/12 dB slope (LP/HP)
Crossover point (Hz) 4500 Hz
Size of filter box 145 x 85 x 45 mm ( 5,71 x 3,35 x 1,77 )
Outer diameter of woofer 165 mm (6,5 )
Cone material Black anodized aluminium cone
Magnet size 110 mm (4,33 )
Mounting depth 75 mm ( 3 )
Mounting hole 145 mm (5,7 )

T/S parameters
single V/C
Fs 58,7 Hz Re 2,3 Ohm Qms 3,5
Vas 9,65 liter Vas 0,34 Cuft Qes 0,76
Qts 0,62 Sd 147 cm BL 5,06
